Lab 3: MAUP in Practice — Tessellations and Point-in-Polygon

National Dam Inventory (NID): From Counts to Local Clustering

Background

In this lab we will explore the impacts of tessellated surfaces and the modifiable areal unit problem (MAUP) using the National Dam Inventory maintained by the United States Army Corps of Engineers. The work requires writing reusable functions and careful consideration of feature aggregation/simplification, spatial joins, and data visualization. The end goal is to visualize the distribution of dams and their purposes across the country.

DISCLAIMER: This lab can be computationally intensive. For some steps you may be processing hundreds of millions of relations; run code chunk-by-chunk during development rather than knitting the whole document repeatedly. Your final knit may take a few minutes. Be proud — the report will summarize analyses over very large geometric relations.

This lab covers 4 main skills:

  1. Tessellating surfaces to discretize space
  2. Geometry simplification to expedite expensive intersections
  3. Writing functions to automate repetitive reporting and mapping tasks
  4. Point-in-polygon counts to aggregate point data

Graduate-Level Expectations

In addition to producing correct code and outputs, your submission should:

  • Justify methodological choices: Why did you choose a particular tessellation keep percentage for simplification? How did you balance computational efficiency with map detail?
  • Document performance impacts: Measure and report computation time and geometric accuracy changes resulting from simplification. How do results differ?
  • Apply spatial reasoning: Use spatial predicates (e.g., st_touches, st_contains) to identify and describe geometric relationships in the dam dataset that raw counts cannot reveal.
  • Compare across methods: When multiple tessellation approaches yield different clustering patterns, explain which pattern better supports real-world dam management decisions and why.
  • Connect to lecture: Explicitly cite the MAUP problem, simplification algorithms (Douglas-Peucker vs. Visvalingam), and spatial predicate definitions from week 3 lectures in your analysis.

Libraries

Question 1:

Here we will prepare five tessellated surfaces from CONUS and write a function to plot them in a descriptive way.

Step 1.1

First, we need a spatial file of CONUS counties. For future area calculations we want these in an equal area projection (EPSG:5070).

To achieve this:

  • get an sf object of US counties (AOI::aoi_get(state = "conus", county = "all"))

  • transform the data to EPSG:5070

Step 1.2

For triangle based tessellations we need point locations to serve as our “anchors”.

To achieve this:

  • generate county centroids using st_centroid

  • Since, we can only tessellate over a feature we need to combine or union the resulting 3,108 POINT features into a single MULTIPOINT feature

  • Since these are point objects, the difference between union/combine is mute

Step 1.3

Tessellations/Coverage’s describe the extent of a region with geometric shapes, called tiles, with no overlaps or gaps.

Tiles can range in size, shape, area and have different methods for being created.

Some methods generate triangular tiles across a set of defined points (e.g. Voronoi and Delaunay triangulation)

Others generate equal area tiles over a known extent (st_make_grid)

For this lab, we will create surfaces of CONUS using using 4 methods, 2 based on an extent and 2 based on point anchors:

Tessellations :

  • st_voronoi: creates a Voronoi tessellation

  • st_triangulate: triangulates a set of points (not constrained)

Coverages:

  • st_make_grid: creates a square grid covering the geometry of an sf or sfc object

  • st_make_grid(square = FALSE): creates a hexagonal grid covering the geometry of an sf or sfc object

  • The side of coverage tiles can be defined by a cell resolution or a specified number of cell in the X and Y direction

For this step:

  • Make a voroni tessellation over your county centroids (MULTIPOINT)
  • Make a triangulated tessellation over your county centroids (MULTIPOINT)
  • Make a gridded coverage with n = 70, over your counties object
  • Make a hexagonal coverage with n = 70, over your counties object

In addition to creating these 4 coverage’s we need to add an ID to each tile.

To do this:

  • add a new column to each tessellation that spans from 1:n().

  • Remember that ALL tessellation methods return an sfc GEOMETRYCOLLECTION, and to add attribute information - like our ID - you will have to coerce the sfc list into an sf object (st_sf or st_as_sf)

Last, we want to ensure that our surfaces are topologically valid/simple.

  • To ensure this, we can pass our surfaces through st_cast.

  • Remember that casting an object explicitly (e.g. st_cast(x, "POINT")) changes a geometry

  • If no output type is specified (e.g. st_cast(x)) then the cast attempts to simplify the geometry.

  • If you don’t do this you might get unexpected “TopologyException” errors.

Step 1.4

If you plot the above tessellations you’ll see that the Voronoi, Delaunay triangulation, hexagon, and square grids all produce regions far beyond the boundaries of CONUS.

We need to cut these boundaries to CONUS borders.

To do this, we need two different approaches: - st_intersection() for Voronoi and Delaunay (these tessellations create geometries that extend infinitely/far beyond the study area; intersection clips them at the exact boundary) - st_filter() for hexagon and square grids (these regular grids are already designed to fit; filtering keeps only the tiles that intersect CONUS)

Either way, we’ll need a geometry of CONUS to serve as our clipping feature. We can get this by unioning our existing county boundaries.

Step 1.5

With a single feature boundary, we must carefully consider the complexity of the geometry. Remember, the more points our geometry contains, the more computations needed for spatial predicates our differencing. For a task like ours, we do not need a finely resolved coastal boarder.

To achieve this:

  • Simplify your unioned border using the Visvalingam algorithm provided by rmapshaper::ms_simplify.

  • Choose what percentage of vertices to retain using the keep argument and work to find the highest number that provides a shape you are comfortable with for the analysis:

Validation Checkpoint (Optional)

After simplification, verify the boundary is still valid and covers all dams:

Code
# Check: Is the simplified boundary valid?
st_is_valid(boundary_simplified)

# Check: Does it still contain all of CONUS?
st_bbox(boundary_simplified)  # Should cover roughly [-125, 24] to [-66, 49]

# Check: Visual comparison
plot(boundary_original, main = "Original")
plot(boundary_simplified, main = "Simplified")
Simplification: Boundary Only, Not Tessellation

Important distinction: This step simplifies the CONUS boundary container we use for clipping the tessellated surfaces. Simplification affects only the geometry of the clipping operation — it speeds up the intersection computation by reducing boundary vertices. Your tessellation tiles themselves remain high-resolution and unchanged. You are not simplifying the tessellation itself, only the container we clip with.

  • Once you are happy with your simplification, use the mapview::npts function to report the number of points in your original object, and the number of points in your simplified object.

  • How many points were you able to remove? What are the consequences of doing this computationally?

  • Finally, crop all four grids to the CONUS boundary—but using different methods:
    • Voronoi & Delaunay (geometry-based tessellations): Use st_intersection() to cut these geometries at the CONUS boundary. These tessellations create boundaries that extend well beyond CONUS; intersection actually trims them.
    • Hexagon & Square grids (regular grids): Use st_filter() to keep only tiles that touch CONUS. These grids are already regularly aligned; filtering just discards edge tiles without modifying them.
Why Different Cropping Methods?

The distinction matters for your spatial analysis:

  • st_intersection() on Voronoi/Delaunay: Produces edges/boundaries that align precisely with the CONUS border. Tiles at the edge are cut, not discarded. This is geometrically accurate but creates irregular edge shapes.

  • st_filter() on hexagon/square grids: Keeps only complete regular tiles that touch CONUS, discarding edge tiles. The boundary is a stair-step pattern following the regular grid.

In Q3, when you compare these tessellations, you’ll notice that Voronoi and Delaunay have denser tile coverage (e.g., ~2800–6200 tiles) because they extend to the exact boundary. Hexagons and squares have fewer tiles (e.g., ~1900–2000) because they’re bound to a regular grid. This difference affects spatial statistics: denser tessellations reveal finer-grained patterns; coarser tessellations show broader regional structure. This is part of the Modifiable Areal Unit Problem (MAUP).

Step 1.6

The last step is to plot your tessellations. We don’t want to write out 5 ggplots (or mindlessly copy and paste 😄)

Instead, lets make a function that takes an sf object as arg1 and a character string as arg2 and returns a ggplot object showing arg1 titled with arg2.

The form of a function is:

Code
name = function(arg1, arg2) {

  ... code goes here ...

}

For this function:

  • The name can be anything you chose, arg1 should take an sf object, and arg2 should take a character string that will title the plot

  • In your function, the code should follow our standard ggplot practice where your data is arg1, and your title is arg2

  • The function should also enforce the following:

    • a white fill

    • a navy border

    • a size of 0.2

    • `theme_void``

    • a caption that reports the number of features in arg1

      • You will need to paste character stings and variables together.

Step 1.7

Use your new function to plot each of your tessellated surfaces and the original county data (5 plots in total):

Question 2:

In this question, we will write out a function to summarize our tessellated surfaces.

Step 2.1

First, we need a function that takes a sf object and a character string and returns a data.frame.

For this function:

  • The function name can be anything you chose, arg1 should take an sf object, and arg2 should take a character string describing the object

  • In your function, calculate the area of arg1; convert the units to km2; and then drop the units

  • Next, create a data.frame containing the following:

    1. text from arg2

    2. the number of features in arg1

    3. the mean area of the features in arg1 (km2)

    4. the standard deviation of the features in arg1

    5. the total area (km2) of arg1

  • Return this data.frame

Step 2.2

Use your new function to summarize each of your tessellations and the original counties.

Step 2.3

Multiple data.frame objects can bound row-wise with bind_rows into a single data.frame

For example, if your function is called sum_tess, the following would bind your summaries of the triangulation and voroni object.

Code
bind_rows(
  sum_tess(triangulate_grid, "triangulation"),
  sum_tess(voronoi_grid, "voronoi")
)

Step 2.4

Once your 5 summaries are bound (2 tessellations, 2 coverage’s, and the raw counties) print the data.frame as a nice table using knitr/kableExtra/flextable or your preferred table formatting package.

Step 2.5

Comment on the traits of each tessellation. Be specific about how these traits might impact the results of a point-in-polygon analysis in the contexts of the modifiable areal unit problem and with respect computational requirements.

Question 3: Dam Distribution Analysis & Tessellation Selection

The data we will analyze in this lab are from the U.S. Army Corps of Engineers National Dam Inventory (NID). This dataset documents ~91,000 dams in the United States and includes attributes such as design specifications, risk level, age, and purpose.

Dam management agencies face a critical question: Where are dams actually clustered, and how do I visualize that clustering in a way that supports infrastructure planning decisions? The answer depends on your choice of geographic boundaries—that is, your tessellation. Different tessellations will reveal different patterns of dam concentration. Your job in this question is to:

  1. Quantify dam distributions across multiple tessellation methods
  2. Understand how the modifiable areal unit problem (MAUP) creates different narratives from the same underlying data
  3. Select and justify the tessellation that best supports management decisions about dam clustering

For the remainder of this lab we will analyze the distributions of these dams using point-in-polygon analysis.

Step 3.1

In the tradition of this class - and true to data science/GIS work - you need to find, download, and manage raw data. THe NID dataset is available as a CSV download from the USACE website here. Grab the CSV.

  • Return to your RStudio Project and read the data in using the readr::read_csv
    • Use janitor::clean_names() to standardize column names to snake_case (tidy data convention)
    • After reading the data in, be sure to remove rows that don’t have location values (!is.na())
    • Convert the data.frame to a sf object by defining the coordinates and CRS
    • Transform the data to a CONUS AEA (EPSG:5070) projection - matching your tessellation
    • Filter to include only those within your CONUS boundary
Data Cleaning with janitor

The NID CSV has messy column names (all caps with spaces). The janitor::clean_names() function converts them to clean snake_case (LONGITUDE → longitude, DAM NAME → dam_name). This is a lightweight utility that saves time and prevents typos in downstream code. It’s part of data wrangling best practice.

Code
# Prefer a local NID CSV named `nation.csv`; otherwise download to that filename
nid_url <- "https://nid.sec.usace.army.mil/api/nation/csv"
dir.create("data", showWarnings = FALSE)
nid_dest <- "data/nation.csv"
if (file.exists(nid_dest)) {
  message("Using local NID file: ", nid_dest)
} else {
  tryCatch({
    message("Downloading NID CSV to: ", nid_dest)
    download.file(nid_url, nid_dest, quiet = FALSE, mode = "wb")
  }, error = function(e) {
    message("NID download failed: ", e$message)
  })
}

# read the CSV (will error if download failed and file missing)
if (!file.exists(nid_dest)) stop("NID CSV not found at ", nid_dest)
dams <- readr::read_csv(nid_dest, skip =1, show_col_types = FALSE) |>
  janitor::clean_names()

usa <- AOI::aoi_get(state = "conus") %>%
  st_union() %>%
  st_transform(5070)

dams2 <- dams %>%
  filter(!is.na(latitude)) %>%
  st_as_sf(coords = c("longitude", "latitude"), crs = 4326) %>%
  st_transform(5070) %>%
  st_filter(usa)

Step 3.2

Following the in-class examples develop an efficient point-in-polygon function that takes:

  • points as arg1,
  • polygons as arg2,
  • The name of the id column as arg3

The function should make use of spatial and non-spatial joins, sf coercion and dplyr::count. The returned object should be input sf object with a column - n - counting the number of points in each tile.

Point-in-Polygon Function Design Notes

  1. CRS Matching: Ensure points and polygons are in the same CRS before calling st_join(). If they differ, use st_transform() to align them first.

  2. Empty Polygons: st_join(...) %>% count(id) creates one row per intersection found. Polygons with zero intersections will appear in the result with n = 0 only if you use a left join (default for st_join()). If a polygon has no points, make sure your result still includes it; if not, use st_join(...) %>% right_join(...) or initialize counts explicitly.

  3. Sparse vs. Dense Matrices: In this step you’re not creating matrices. However, in Q6.1 you’ll use st_touches(..., sparse = FALSE) to build neighbor matrices explicitly. Here in Q3, st_join() handles the spatial predicate internally (st_intersects by default), so you won’t set sparsity—just know that st_join() scales well to large datasets. For troubleshooting performance: if your function runs slowly with 91,000 dams, check whether your tessellation polygons are topologically simple (use st_is_valid()).

Step 3.3

Apply your point-in-polygon function to each of your five tessellated surfaces where:

  • Your points are the dams
  • Your polygons are the respective tessellation
  • The id column is the name of the id columns you defined.

Step 3.4

Lets continue the trend of automating our repetitive tasks through function creation. This time make a new function that extends your previous plotting function.

For this function:

  • The name can be anything you chose, arg1 should take an sf object, and arg2 should take a character string that will title the plot

  • The function should also enforce the following:

    • the fill aesthetic is driven by the count column n

    • the col is NA

    • the fill is scaled to a continuous viridis color ramp

    • theme_void

    • a caption that reports the number of dams in arg1 (e.g. sum(n))

      • You will need to paste character stings and variables together.

Step 3.5

Apply your plotting function to each of the 5 tessellated surfaces with Point-in-Polygon counts:

Step 3.6

Policy Analysis: Tessellation and Decision-Making

Now that you have dam counts across all five tessellation methods, compare the results. Specifically:

a. Create a side-by-side visualization (faceted or small multiples) showing dam clustering under each of the five tessellations. Use patchwork or cowplot to arrange the 5 plots you created in Step 3.5 for direct visual comparison.

b. Identify 2–3 geographic regions where tessellation choice produces substantially different patterns (e.g., one method shows a clear hotspot while another shows diffuse distribution). For each region, describe the pattern difference and explain why the tessellation geometry creates divergent results. Reference the characteristics from your Q2 summary (number of tiles, mean area, standard deviation).

c. Which single tessellation would you recommend to a dam operations manager seeking to understand geographic clustering? Justify your choice by addressing: - Does the tessellation align with natural or management decision-making units (e.g., river basins, states, hydrologic regions)? - Does it reveal meaningful patterns without over-fragmenting the landscape or creating artificial boundaries? - How does MAUP influence your recommendation—are other tessellations equally valid, just for different questions? - How did simplification affect your choice? Would a coarser or finer simplification (different keep percentage) change your recommendation? - What does “best supports management decisions” mean concretely in your context—does it matter more that hot spots are obvious, or that boundaries align with jurisdictions?

Your answer should be 3–4 paragraphs and grounded in the actual visualizations and patterns you observe from your tessellation comparisons.

Question 4

The NID provides a comprehensive data dictionary here. In it we find that dam purposes are designated by a character code.

These are shown below for convenience (built using knitr on a data.frame called nid_classifier):

NID 2019: Dam Purposes
abbr purpose
I Irrigation
H Hydroelectric
C Flood Control
N Navigation
S Water Supply
R Recreation
P Fire Protection
F Fish and Wildlife
D Debris Control
T Tailings
G Grade Stabilization
O Other

  • In the data dictionary, we see a dam can have multiple purposes.

  • In these cases, the purpose codes are concatenated in order of decreasing importance. For example, SCR would indicate the primary purposes are Water Supply, then Flood Control, then Recreation.

  • A standard summary indicates there are over 400 unique combinations of dam purposes:

Code
unique(dams2$PURPOSES) %>% length()
[1] 0
  • By storing dam codes as a concatenated string, there is no easy way to identify how many dams serve any one purpose… for example where are the hydro electric dams?

To overcome this data structure limitation, we can identify how many dams serve each purpose by splitting the PURPOSES values (strsplit) and tabulating the unlisted results as a data.frame. Effectively this is double/triple/quadruple counting dams bases on how many purposes they serve:

The result of this would indicate:

Step 4.1

  • Your task is to create point-in-polygon counts for at least 4 of the above dam purposes:

  • You will use grepl to filter the complete dataset to those with your chosen purpose

  • Remember that grepl returns a boolean if a given pattern is matched in a string

  • grepl is vectorized so can be used in dplyr::filter

For example:

Code
# Find flood control dams in the first 5 records:
dams2$PURPOSES[1:5]
NULL
Code
grepl("F", dams2$PURPOSES[1:5])
logical(0)

For your analysis, choose at least four of the above codes, and describe why you chose them. Then for each of them, create a subset of dams that serve that purpose using dplyr::filter and grepl

Finally, use your point-in-polygon function to count each subset across your cropped tessellation from Q1.4 (e.g., hexagon_clipped or square_clipped).

Step 4.2

  • Now use your plotting function from Q3 to map these counts on the cropped tessellation.

  • But! you will use gghighlight to only color those tiles where the count (n) is greater then the (mean + 1 standard deviation) of the set

  • Since your plotting function returns a ggplot object already, the gghighlight call can be added “+” directly to the function.

  • The result of this exploration is to highlight the areas of the country with the most

Step 4.3

Comment on the geographic distribution of dams you found. Does it make sense? How might the tessellation you chose impact your findings? How does the distribution of dams coincide with other geographic factors such as river systems, climate, ect?

Optional: Connect to Q6 — For purposes you chose in Q4, hypothesize in 1–2 sentences: “Will [irrigation/hydroelectric] dams show the same LISA hotspots as all dams in Q6, or different patterns? Why?” After completing Q6, revisit this hypothesis.

Question 5: Spatial Correlation of Dam Attributes — Introduction to Spatial Regression

Dam characteristics—such as age, surface area, storage capacity, and purpose—vary geographically. Understanding the spatial structure of these relationships is foundational to spatial regression modeling (upcoming topics). In this question, you’ll examine whether dam attributes exhibit spatial dependence and assess whether neighboring tiles have correlated characteristics.

Spatial Regression Motivation (Week 3-1 Foundation)

Standard regression assumes observations are independent. But spatial data often violates this: dams in the Pacific Northwest likely share design and management practices, leading to spatially correlated residuals. This spatial dependence can bias confidence intervals and inflate significance tests in standard OLS regression.

The solution involves spatial lag models (Spatial Autoregressive, SAR) or spatial error models (SEM) that explicitly model dependence via neighbor relationships. This lab asks: Do your tessellation neighborhoods reveal spatial structure in dam attributes?

For this question, use your cropped tessellation from Q1.4 (your recommended tessellation from Q3, clipped to the CONUS boundary). You’ll examine whether dam attributes (age, size, count) are spatially autocorrelated—evidence that neighboring tiles have similar values, violating independence assumptions.

Step 5.1

Aggregate Dam Attributes by Tile

Using your cropped tessellation from Q1.4 (your recommended grid from Q3, clipped to CONUS boundary), compute mean and variance of key dam attributes within each tile. The NID dataset typically includes:

  • Age: year_completed or similar (compute mean age per tile)
  • Size: surface_area_acres or normal_pool_elevation (compute mean per tile)
  • Purpose codes: purposes field (compute dominant purpose per tile; count of dams by purpose)

Aggregate as follows:

Code
# Suggested workflow (write your own implementation):
# 1) spatial join dams to your cropped tessellation
# 2) group by tile id and summarize n_dams, mean_year_completed, mean_surface_area
# 3) join summaries back to geometry and preserve zero-dam tiles
# 4) inspect distributions before mapping

Produce visualizations showing spatial patterns:

  • Map 1: Mean dam age by tile (use viridis scale)
  • Map 2: Mean surface area by tile
  • Map 3: Dam count by tile (you already have this from Q3)

Do you see geographic clustering of old vs. new dams? Large vs. small dams?

Step 5.2

Neighbor Correlation: Local Spatial Variation

For your tessellation’s neighbor matrix, compute the spatial lag of dam attributes: the average value of an attribute in a tile’s neighbors. This reveals whether spatial neighbors have similar dam attributes—a key signal that observations are not independent (violating OLS assumptions).

Critical: NA Handling in Spatial Lag Calculations

Many tiles may have zero dams (NAs for attributes like mean_year_completed, mean_surface_area). When you compute the spatial lag via matrix multiplication, these NAs propagate and can cause cor() to fail with “no complete element pairs.”

Solution: Impute before spatial lag calculation

  1. Replace NAs in the attribute with the global mean (mean across all tiles, ignoring NAs)
  2. Compute the spatial lag on the imputed data
  3. When correlating, use only tiles that had original data (not imputed)

This preserves statistical integrity: neighbors’ contributions are computed correctly, but you only correlate where real observations exist.

Code
# Suggested workflow (write your own implementation):
# 1) build vectors for count, age, and size attributes by tile
# 2) handle NAs explicitly before matrix multiplication
# 3) compute spatial lag as W_std %*% attribute
# 4) correlate each attribute with its lag
# 5) report values and classify as weak/moderate/strong with your own thresholds

Summarize in a table:

Code
# Create a compact summary table with:
# - attribute name
# - correlation with spatial lag
# - qualitative strength label
# Then add a 1-2 sentence interpretation below the table.

Step 5.3

Global Question: Do neighboring tiles resemble each other overall, or is the pattern weak?

Create a single Moran’s I scatterplot for one dam attribute from Step 5.2 (for example, mean year completed or dam count). Use standardized values on both axes: the attribute on the x-axis and the spatial lag on the y-axis. The plot should show whether points concentrate along the diagonal or remain widely dispersed.

Your interpretation should focus on the overall pattern, not on specific regions. In particular, explain whether the correlation from Step 5.2 suggests strong, moderate, or weak spatial dependence and whether the scatterplot supports that conclusion.

Do not create a geographic map here. Save local hotspot mapping for Q6.

Standardization Details

Why standardize? Centering and scaling puts the attribute and spatial lag on the same scale (mean=0, SD=1), making it easy to identify quadrants and interpret outliers.

scale(x, center=TRUE, scale=TRUE)[, 1]

Returns a numeric vector (not a matrix). Use [, 1] to extract it, or use as.vector() explicitly.

Code
# Suggested workflow (write your own implementation):
# 1) standardize the selected attribute and its spatial lag
# 2) assign HH / LL / HL / LH quadrants by sign of (z, lag_z)
# 3) produce a Moran scatterplot with dashed axes at 0
# 4) report quadrant counts and interpret what dominates

Step 5.4

Global Interpretation of Spatial Patterns

Writing Guide: Interpreting Spatial Correlation

Use this structure to organize your response:

  1. State your findings clearly — cite specific correlation values from your Step 5.2 table. Which attributes show the strongest clustering?
  2. Connect to structure — what does the scatterplot suggest about broad spatial organization, without moving into local mapping yet?
  3. Explain why — relate to dam history, geology, hydrology, or policy at the regional scale
  4. Analyze patterns — describe what the Moran scatterplot and correlation values reveal about overall dam distributions

Write 2–3 paragraphs (400–600 words) addressing:

a. Spatial Clustering Patterns (Quantitative + Geographic)

Which attributes show the strongest spatial lag correlations (from your Step 5.2 table)? Are correlations > 0.5 (strong) or 0.2–0.5 (moderate)?

  • Dam count: Often strongly correlated because high dam density naturally creates neighbors with many dams.
  • Dam age: Likely shows clustering if dams were built in regionally-coherent eras (e.g., 1930s TVA construction, 1960s–70s Western expansion).
  • Dam size: May be clustered if geology/hydrology favors larger dams in specific regions.

For each attribute, describe whether the clustering seems broad or weak. Does the correlation make geographic sense? Why should dam characteristics be similar in neighboring areas?

b. Moran Scatterplot Interpretation (Visualization)

From your Moran scatterplot, describe the spatial distribution of points:

  • Do points cluster near the diagonal, suggesting positive spatial autocorrelation?
  • Are there many outliers away from the diagonal, suggesting weaker dependence or heterogeneous neighborhoods?
  • Does the pattern appear stronger for some attributes than others?

c. Spatial Structure Implications

What do these correlation values and Moran scatterplot patterns tell us about dam infrastructure spatial organization? Given your findings, write a brief conclusion synthesizing: - Are neighboring tiles genuinely similar in dam characteristics, or is the clustering weak? - What management or hydrologic factors drive these patterns? - How do findings from your Moran analysis here compare to what you observed in Q4 (dam purposes geography)?

Note: In future weeks, we’ll explore how spatial structure revealed here relates to statistical modeling of dam attributes.

Step 5.5 (Optional) — Hypothesis Checkpoint

Before moving to Q6, answer this question to verify your understanding:

Given your correlation results from Step 5.2, what do you expect to see in a Moran scatterplot (Q6)?

  • If all correlations are > 0.5: Do you expect most points to cluster in the upper-right (HH) and lower-left (LL) quadrants, or scattered across all four?
  • If correlations are weak (< 0.3): Would you expect many High-Low or Low-High outliers?
  • Based on dam geography (e.g., TVA region, Colorado River Basin), where do you predict hotspots (HH) and coldspots (LL) will concentrate?

Write 2–3 sentences predicting Q6 outcomes before you compute LISA. After Q6, revisit this prediction to see if reality matched your expectation.

Question 6: Local Spatial Autocorrelation (LISA) — Mapping Hotspots and Coldspots

In this question, you’ll analyze LISA using your recommended tessellation from Q3 AND counties as a required comparison unit. This contrast (regular tessellation vs administrative boundaries) reveals MAUP much more clearly than comparing two regular grids.

While global statistics like Moran’s I (Q5) test for clustering “on average,” spatial patterns are rarely uniform. Some regions have dense hotspots (e.g., TVA region with concentrated dam infrastructure), while others are sparse coldspots (remote areas, deserts). Local Indicator of Spatial Autocorrelation (LISA) decomposes global clustering into local patterns, revealing where hotspots and coldspots occur—critical for targeted management interventions.

In this question, you’ll compute LISA using your cropped recommended tessellation (from Q1.4) and CONUS counties as the alternative support. This gives a direct test of how local clustering changes when analysis units shift from equal-area tiles to administrative units.

LISA Concept (Week 3-1 Lectures)

LISA compares each tile’s standardized dam count (\(z_i\)) to the standardized spatial lag (\(\text{lag}_z\)):

\[\text{lag}_z = \frac{1}{w_i} \sum_{j \in N(i)} w_{ij} z_j\]

where neighbors \(j \in N(i)\) are adjacent tiles, and \(w_{ij}\) = row-standardized adjacency weight (1 if touching, 0 otherwise).

The resulting LISA quadrants reveal: - High-High (HH): High dam count, high-count neighbors → hotspot - Low-Low (LL): Low dam count, low-count neighbors → coldspot
- High-Low (HL): High count, low neighbors → potentially isolated cluster edge - Low-High (LH): Low count, high neighbors → potential anomaly or outlier

Step 6.1

Crop your tessellations to ensure consistent boundaries:

a. Use your recommended tessellation from Q3 (e.g., hexagon grid). Clip it to the CONUS boundary with st_filter(tessellation, boundary).

b. Use counties as the required alternative comparison unit (no extra clipping needed if your counties object is already CONUS-only).

c. For each clipped tessellation, recompute dam counts using point-in-polygon joining to ensure correct aggregation within the cropped geometry.

Cropping Tessellations Correctly
# Recommended tessellation (e.g., hexagon_grid)
hex_cropped <- st_filter(hexagon_grid, usa_boundary)

# Required comparison unit: counties (already CONUS)
county_units <- counties_sf

# Recompute dam counts on cropped grids
# (Use your point_in_polygon function or st_join + count pattern)
hex_dams <- st_join(hex_cropped, dams_sf) %>%
  group_by(id) %>%
  summarise(n = n(), .groups = "drop")

county_dams <- st_join(county_units, dams_sf) %>%
  group_by(id) %>%
  summarise(n = n(), .groups = "drop")

Important: Cropping changes tile counts and boundary geometries. Re-aggregate dam counts after cropping to match the new tile geometry.

Step 6.2

Compute neighbors and spatial lag for your recommended tessellation:

a. Create the binary neighbor adjacency matrix using st_touches(..., sparse = FALSE). Include only tiles within the cropped boundary.

b. Remove self-neighbors: diag(W) <- 0

c. Row-standardize weights: divide each row by its sum, handling isolated tiles.

d. Compute spatial lag: \(\text{lag} = W_{\text{std}} \times \text{dam\_counts}\)

e. Standardize both dam counts and spatial lag (z-score normalization).

Validation Checkpoint (Optional but Recommended)

After computing the neighbor matrix, verify it’s valid:

Code
# Check 1: Is the matrix symmetric? (for undirected adjacency)
all(neighbor_matrix == t(neighbor_matrix))

# Check 2: Are all rows row-standardized (divide by row sum)?
rowSums(neighbor_weights)  # Should all be 1 (or 0 for isolated tiles)

# Check 3: Are there isolated tiles (no neighbors)?
sum(rowSums(neighbor_weights) == 0)

# If any isolated tiles, document how you'll handle them in spatial lag calculation

Step 6.3

LOCAL Question: WHERE specifically are high-high, low-low, high-low, and low-high clusters? (Answer: Geographic map showing which regions belong to which quadrant)

Two Visualizations:

a) Moran Scatterplot (Reference): - Same as Q5, showing which tile belongs to which quadrant - Primarily for reference; the interesting insight is now geographic

b) LISA Geographic Map (PRIMARY OUTPUT): - Choropleth map of your tessellation colored by LISA quadrant - HH (red) = hotspots with hotspot neighbors → TVA region, Colorado Basin, etc. - LL (blue) = coldspots with coldspot neighbors → Great Basin, deserts, etc. - HL (yellow) = anomalies: high counts surrounded by sparse tiles (cluster edges) - LH (cyan) = anomalies: sparse tiles surrounded by high-count neighbors (rare)

Key Interpretation: The LISA map reveals which specific regions exhibit local clustering. This is actionable: dense regions need intensive management; sparse regions need different strategies. The quadrant distribution (% of tiles in HH vs. LL) reveals whether the landscape is dominated by hotspots, coldspots, or mixed.

Step 6.4

Comparison with required county baseline:

a. Repeat Steps 6.2–6.3 for counties.

b. REQUIRED DELIVERABLE: Create side-by-side LISA maps of your chosen tessellation (from Q3) and counties in the same figure. Use identical quadrant labels and color mapping in both panels so visual differences reflect unit choice, not styling.

c. Quantitative comparison: For both units, count the number of polygons in each quadrant. Example output: - Hexagon: HH=15 tiles, LL=23 tiles, HL=5 tiles, LH=2 tiles - Counties: HH=205 counties, LL=1300 counties, HL=240 counties, LH=360 counties - Interpretation: Are quadrant distributions similar (robust LISA pattern) or different (MAUP sensitive at local scale)?

d. Interpret: Which unit reveals clustering more clearly for your purpose? Do patterns align between your chosen tessellation and counties, or does MAUP (modifiable areal unit problem) create divergent local structure?

Step 6.5

Geographic Interpretation and Management Implications

Write a 3–4 paragraph synthesis addressing:

a. Geographic hotspots and coldspots: Identify major clustering regions: - Which dams are in HH hotspots? (E.g., TVA dams, Colorado River dams, others?) - Which regions are LL coldspots? (Mountains, deserts, sparse-development areas?) - What management or hydrologic factors explain these patterns?

Specific region example: Choose one HH hotspot (e.g., Tennessee Valley Authority region, Colorado River Basin, California Central Valley) and describe three factors that explain why TVA dams or Colorado River dams cluster. Use geographic knowledge or brief web research if needed.

b. Outliers and anomalies: Are there notable HL or LH tiles? What might explain them?

c. Unit comparison: Does analysis unit choice (hexagon vs. county) affect LISA conclusions? How does MAUP operate at the local scale?

d. Implications for management: How does LISA output inform dam operations, reporting, or policy? - Where should multi-state coordination efforts focus? (HH hotspots) - Which regions have simple management structures? (LL coldspots) - How do your LISA findings from Q6 compare to the dam purpose patterns you identified in Q4? (E.g., do irrigation dams cluster the same way as all dams?) - Where do policies need special attention to local anomalies? (HL/LH outliers)
